xModel NO. | Wind And Solar Power System | Application | Home, Industrial, Commercial |
---|---|---|---|
Specification | Mini, Standard Specification Or Customized | Output Voltage (V) | 220V - 360V |
Work Time (H) | 24h | Mounting Type | Roof Mounting |
Battery Type | Lead-Acid, Lithium Ion | Battery | Lead-Acid Gel Battery |
OEM Or ODM | Accept | Color | White |
System Type | Hybrid Solar PV System | Solar Panel Type | Monocrystalline Silicon, Polycrystalline Silicon |
Load Power (W) | 3kw, 50kw, 30kw, 8kw, 6kw, 20kw, 5kw, 10kw | Application For | Surveillance System |
Output Frequency | 50/60 Hz | Keywords | Wind And Solar Power System |
Type | Photovoltaic Solar Energy System | Product Name | Off Grid Solar System |
Transport Package | Standard Packaging Or Customized | Trademark | HTONETECH |
Origin | Beijing, China | Supply Ability | 50000000pieces/Year |
Shipping Cost | To Be Negotiated| Freight Cost Calculator | After-sales Service | Yes |
Warranty | 2year | Condition | New |
Highlight | 36V Home Solar Battery System,300W Home Solar Battery System |
Product Description



System advantages:
HTONETECH off-grid power supply system, 10,000 sets of successful experience, customized services, one-stop shopping, and products meet CE certification.
1. No risk of depletion;
2. Safe and reliable, no noise, no pollution emissions, absolutely clean
3. Not limited by the geographical distribution of resources, can take advantage of the advantages of building roofs;
4. Generate and supply power on-site without consuming fuel and erecting transmission lines;
5. Energy quality is high;
6. The construction period is short, and the time spent in obtaining energy is short.
Meet the 24H operation of small equipment of 60-100W, and the operation of 3 days in cloudy and rainy days.
key features and benefits of an All-in-One Energy Storage Solar System:
Solar Panels: The system includes solar panels that capture sunlight and convert it into electricity. These panels are typically integrated into the system and optimized for maximum energy production.
Energy Storage: The system incorporates a built-in battery storage system to store excess solar energy for later use. This allows for energy self-sufficiency, even during periods of low solar generation or at night.
Inverter/Converter: An inverter or converter is part of the system to convert the DC (direct current) electricity generated by the solar panels into AC (alternating current) electricity that can be used to power household appliances and devices.
Monitoring and Control: All-in-One systems often include monitoring and control features that allow users to track energy production, consumption, and battery status. This enables users to optimize energy usage, monitor system performance, and make informed decisions.

BLACK MONO SOLAR PANELS
Peak Power Watts:280W(SP280M-60)
Maximum Power Voltage:31.8V
Maximum Power Current: 8.81A
Open Circuit Voltage: 38.8V
Short Circuit Current:9.33A
Dimensions:1650x992x35mm(65.0x39.1x1.38inches)
Weight:18.6 kg (41.0 b)
SOLAX HYBRID INVERTER &DATA LOGGING STICK
Max.DC Input Power.3KW/3.7KW/4.6KW/5KW
Max.DCInput Voltage: 600V
MPPT Voltage Range: 120-550V
Rated Grid Voltage: 230V(EU)
Warranty: 5 Years (STD) 10 Years (Optional)
Wifi Stick For STD, Lan & GPRS Optional
TRIPLE-POWER LITHIUM BATTERY
Capacity(kWh): 4.5/6.3
Operating Voltage(Vdc): 85-118
Max. charge/discharge Current(A):30A
Charge/Discharge Current (A): 25A
Standard Power(kW):25
Maximum Power(kW):3
T-BAT system safety: CE, FCC, RCM, TUV (IEC 62619)
PV MOUNTING SYSTEM
Mounting Rail & Rail Splice Kit: Al6005 & SUS304Bolt.
Mid & End Clamps: 35,40,45,50mm
L Foot Asphalt Shingle Moount & Hanger BoltOptional
Cable Clip & Tie Optional
Ground Clip & Lugs Optional
Components | SP3KW-HY | SP3.7KW-HY | SP4.6KW-HY | SP5KW-HY |
280W Mono Solar Panel | 12 Piece | 14 Piece | 18 Piece | 20 Piece |
Dc Disconnect Switch | 1 Piece | 1 Piece | 2 Piece | 2 Piece |
Hybrid Inverter | X1-HYBRID-3.0T | X1-HYBRID-3.7T | X1-HYBRID-4.6T | X1-HYBRID-5.0T |
Triple Power Battery | 4.5 kWh | 4.5 kWh | 6.3 kWh | 6.3 kWh |
Dc Cable 4mm2 | 100 meter | 100 meter | 200 meter | 200 meter |
AC Disconnect Switch | 1 Piece | 1 Piece | 1 Piece | 1 Piece |
MC4 Connector | 10 | 10 | 15 | 15 |
Mounting System | Standards Pitched Roof ( Customized Optional) | |||
PV Tools | 1 Set |


















1. Q: Are you a factory or a trading company?
A: We are a professional Solar Panels Manufacturer in China
2. How can we guarantee the quality of the product?
A: Always provide the favored buyer with a pre-production sample before mass production; Always test every product before despatching the shipments;
3. What products we can supply you?
A: Solar panels, inverter, controller, cable, support frame, and other solar power systems
4. Q: Can the product's pricing be cheaper?
A: Of course, you will be offered a very good discount with large quantities.
5.. Q: Can print our company's logo on the PV panels?
A: Yes! And we accept OEM&ODM orders.
